MVM ZX Grinding Machine

MVM ZX Grinding Machine

Grinder for chipper knives and recycling blades

The ZX model grinder is available in two versions, with grinding lengths of either 1000mm or 1230mm. Featuring a rotating magnetic chuck, it is the perfect machine for sharpening paper blades, chipper knives used in wood grinders, and recycling blades for plastic grinders.

Built to Your Requirements

Delivered Within 12 Weeks

Exclusive UK Supplier

Contact us for more details:

DOWNLOAD BROCHURE
Technical Features

Technical Features

  • Cast iron machine bed
  • Grinding motor 1,5 kW (2 HP) - 2800 RPM
  • Automatic downfeed grinding head with automatic stop at preset height
  • Tilting head to grind hollow surfaces
  • Carriage run guides covered with replaceable hardened steel guides
  • 90° rotating knife-mounting chuck
  • Coolant pump
  • Chain driven carriage
  • Supplied with stepped blocks to grind 4 overlapping planer blades simultaneously
Optional Extras

Optional Extras

  • Base
  • Magnetic chuck
  • Variable carriage speed 1-11 m/min
  • Edge reference bar
  • External tank with additional pump
  • Grinding motor 2,2 kW (3 HP)
  • Switch run adjustment
  • Camping device for Tersa, Centrofix, Terminus, Kanefusa, Sinus, Weinig knives
  • Magnetic chuck for hard metal inserts.
